CUTTING AND SEWING INSTRUCTIONS
|
|
Step 1
|
Cut a piece of nylon screening 14" x 22" (finished size 9" x 11")
|
|
Step 2
|
Fold in half and find center front for placement of the design. Allow for editing
on screen if lettering is to be added.
|
|
Step 3
|
Hoop the stabilizer. Score the stabilizer and peel the backing from stabilizer.
|
|
Step 4
|
Place the back of the screening on the stabilizer.
|
|
Step 5
|
Open Embroidery Edit.
|
|
Step 6
|
Place the embroidery card in the machine. Select Design #14, press SET and EDIT
END.
|
|
Step 7
|
If desired, add lettering using the built in alphabet. Touch the lettering icon,
select a font and add desired letters. Edit, array, and space, as desired. Figure #1
|
|
Step 8
|
Stitch out the design and remove from the hoop.
|
|
Step 9
|
Fold the top and bottom edges over and pin the zipper in place. Figure #2
|
|
Step 10
|
Attach the Open Toe foot and sew the zipper in using a small zig zag stitch close
to the edge of the zipper. Use the right edge of the open toe foot against the teeth
of the zipper as a guide.
|
|
Step 11
|
Unzip the zipper half way and turn the bag wrong sides out.
|
|
Step 12
|
Fold the bag so the zipper faces the front side.
Figure #2
|
|
Step 13
|
Trim extra turned down edge of screen away from the back of the stitched zipper.
|
|
Step 14
|
Cut a 4" piece of gross grain ribbon, fold in half and place above the zipper facing into the bag.
|
|
Step 15
|
To allow a little fullness at the bottom of the bag, fold the bottom edge up ½". Figure #3
|
|
Step 16
|
Sew side seams, slowing the speed down when stitching thru the plastic zipper.
|
|
Step 17
|
Trim off the excess seam allowance and zipper.
Figure #4
|
|
Step 18
|
Turn right sides out thru the zipper opening.
|
|
Step 19
|
Soak to remove water soluble stabilizer.
|
