PJ863

Brother PocketJet PJ-863 Full-Page, High-Res, Bluetooth® & USB-C® Thermal Mobile Printer

Name: Brother PocketJet PJ-863 Full-Page, High-Res, Bluetooth® & USB-C® Thermal Mobile Printer
Brand: Brother
SKU: PJ863
Price: 563 USD

$563.00

current price $563.00

Compact and Fast 8.5" Wide Mobile Printing

Bluetooth, MFI, USB C Communications/Charging, Windows Drivers, SDKs, & Emulations

Optional Battery, Consumables and Carrying/Mounting Cases

About the Product

In the Box

Specifications

Detailed technical specs to help you understand performance, compatibility, and requirements.

Connectivity

Compatibility

Dimensions

General

Paper Handling

Power

Print Features

Consumables

Cut

Environment Compatibility

Features

Media

Print Operations

What’s Included

Feature	Value
Warranty	2 Year Premier Limited Warranty
Warranty Type	Select Service

Feature	Value
Apps	Print Service Plugin, Support Center, iPrint&Scan, PJ-673 Print, Print SDK Demo, RJ-4040 Print, Mobile Transfer Express, Mobile Deploy
Communications Interfaces	USB-C Ver 2.0, Bluetooth® Ver 5.2, MFi, NFC
OS Support Link	https://support.brother.com/g/b/oslist.aspx?c=us&lang=en&prod=pj863eus
Print Driver Compatibility	Windows®, Mac®, Linux For the most up-to-date compatibility, visit our Support Page
Print Driver Support Link	https://support.brother.com/g/b/downloadtop.aspx?c=us&lang=en&prod=pj863eus

Feature	Value
OS Compatibility	Windows®, Mac®, Linux, Mobile Android™, Mobile iOS® For the most up-to-date compatibility, visit our Support Page
OS Printing	Windows Mobile®, Android™, iOS®, Apple Airprint®, Google Cloud Print™, Mopria™
Support Software	Software / Document Installer, P-Touch Editor, P-Touch Transfer, Printer Setting Tool, P-touch Transfer Express, Driver Deployment Wizard, Firmware Update Tool, Firmware for Network Connection, BRAdmin Light / Agent / Professional

Feature	Value
Weight	Without battery: 0.95lbs (430g) With battery: 1.34lbs (610g)
Available Color	Black
Flash Memory	32MB
RAM	32MB
Channel Protected	Yes

Feature	Value
Battery	Rechargeable Li-ion battery, replaceable, 10.8V
Battery Charging Options	AC adapter, DC car adapter, USB-C
Battery Charging Time	With AC adapter: 2hrs With car adapter: 2hrs With USB-C: 2hrs
Battery Yield	600 pages per charge
Power	Input: 15V DC 4.0A
Battery Charge Time	3 Hours
Battery Requirements	Rechargeable Li-ion Battery (PA-BT-002)
Power Management	Auto Power On/Off
Battery Life	300 Cycles
Power Source Options	AutoRanging Power Supply, Replaceable Rechargeable Battery, Vehicle Power Adapter, Forklift Power Adapter

Feature	Value
Emulations	Raster_P, P-touch Template, ZPL II
Linear Barcodes	CODE39, ITF (I-2/5), EAN-8( JAN8), EAN-13 (JAN13), UPC-A, UPC-E, CODABAR (NW-7), CODE128, GS1-128 (UCC/EAN-128), POSTNET, GS1 DataBar (RSS), UPC/EAN EXTENSION, MSI, Intelligent Mail Barcode, Industrial 2-of-5, Standard 2-of-5 Downloadable barcodes available
Stored Templates	Up to 256 templates
Bitmap Fonts	Helsinki Brussels Letter Gothic
Outline Fonts	Helsinki Brussels Letter Gothic
Print Commands	Raster_P ESC/P_P ESC/P_B P-touch Template
2D Barcodes	QR Code, PDF417, MaxiCode, Aztec, Micro QR Code, MicroPDF417, DataMatrix, GS1 Databar Composite Downloadable barcodes available
Energy Conservation Certifications	Energy Star certified

Feature	Value
Consumable Roll Core ID Size	Full Page Documents
Media Width Max	8.5" (215.9mm)
Consumable Format	Extended Cut Sheet, Fanfold Media, Roll with Continuous Media, Roll with Perforated Media, Roll with Die Cut Media

Feature	Value
Operating Environment	14°F - 122°F (-10°C - 50°C)
Storage Environment	-4°F - 140°F (-20°C - 60°C)

Feature	Value
In the Box	Printer
Memory	256MB DRAM, 64MB flash (30MB available)
Operating Temperature / Humidity	Printing with battery/car adapter: 14° F to 122° F (-10° C to 50° C)Printing with AC adapter: 14° F to 104° F (-10° C to 40° C)Charging: 32° F to 104° F (0° C to 40° C)20% to 80% non-condensing
Safety	UL, CSA
Sealing Certification	IP54 with case
Storage Temperature / Humidity	-4° F to 140° F (-20° C to 60° C), 20% to 80% non-condensing
