Digital Color All-in-One with Wireless Networking and Duplex
About the Product
Reliable, High-Impact Color with Full Duplex for Small Businesses. The Brother MFC-9340CDW is the perfect choice for small businesses looking for a fast, reliable digital color All-in-One with duplex (2-sided) printing with the time-saving addition of single-pass duplex scanning and faxing. It's packed with features for big business like a 3.7" touchscreen display and wireless networking, but this affordable, compact All-in-One fits the small business workspace and budget. It prints and copies high-impact color and crisp black documents at up to 23ppm and optional high-capacity color toners are available to help reduce cost per page. The MFC-9340CDW is ideal for any small business with a primary need to print black business documents, but with the occasional desire to print professional-quality color documents in-house. It also offers the convenience of wireless printing from your mobile device via‡ AirPrint®, Brother iPrint&Scan and Wi-Fi Direct®.
Main Features
- Blazing Fast Printing. Fast color and black printing - up to 23ppm to help improve your productivity.
- 3.7" Color Touchscreen Display. Easily navigate menus by tapping or swiping on the 3.7" color Touchscreen display with Web Connect‡. Connect to the web directly from the Touchscreen display to access your account on EVERNOTE®, DROPBOX, BOX or more‡.
- High-Impact Business Printing. Produce crisp black and high-impact color business documents at up to 600 x 2400 dpi resolution using Brother's Digital LED print technology.
- Flexible Connectivity. Built-in wireless and Ethernet network interfaces to install on a wired or wireless network or connect locally to a single computer via USB‡.
- Versatile Paper Handling. 250-sheet capacity paper tray adjustable for letter or legal and a straight-through paper path via manual feed slot for envelope printing.
- Help Lower Your Operating Costs. High capacity color toners available (approx. 2,200 pages each‡) to help lower your cost per copy.
- 35-page Capacity Auto Document Feeder. Convenient for copying, scanning or faxing multi-page documents (up to legal size).
- High Quality Scanning. Up to 19200 x 19200 dpi (int.) resolution with a variety of "scan to" features.
- Mobile Device Printing. Wireless printing from your mobile device via‡: AirPrint®, Brother iPrint&Scan and Wi-Fi Direct®.
- At your side support. free online, live chat or phone support for the life of your product.
- Automatic Duplex Printing. Automatic two-sided printing to help save paper.
- Advanced Duplex Capability. Single-pass duplex copying and scanning; simultaneously scan both sides of the page for fast, automatic two-sided scanning and copying.
- Help Control Your Color Printing Costs. Use the Secure Function Lock feature to set color page counts or restrict color printing for up to 25 users.
- USB Direct Interface. Print from or scan to your USB flash memory drive‡.
Specifications
| Mobile Device Compatibility‡ | AirPrint®, Google Cloud Print™, Brother iPrint&Scan, Mopria™ , Wi-Fi Direct® |
|---|---|
| One-Push Wireless Setup | AOSS, Wi-Fi Protected Setup™ |
| Standard Interface(s) | Wireless 802.11 b/g/n, Ethernet, 10/100 Base-TX Ethernet, Wi Fi Direct, Hi-Speed USB 2.0 |
| Standard Network Features‡ | Printing, Scanning, PC Fax Send/Receive |
| Supported Network Protocols (IPv4) | ARP, RARP, BOOTP, DHCP, APIPA (Auto IP), WINS/NetBIOS Name Resolution, DNS Resolver, mDNS, LLMNR Responder, LPR/LPD, Custom Raw Port/Port 9100, IPP/IPPS, FTP Client and Server, TELNET Server, HTTP/HTTPS Server, TFTP Client and Server, SMTP Client, APOP, POP Before SMTP, SMTP Auth, SNMPv1/v2c/v3, ICMP, LLTD Responder, Web Services (Print/Scan), CIFS Client, SNTP Client, SSL/TLS |
| Supported Network Protocols (IPv6) | SSL/TLS, LLTD Responder, NDP, RA, DNS Resolver, mDNS, LLMNR Responder, LPR/LPD, Custom Raw Port/Port 9100, IPP/IPPS, SMTP Client, FTP Client and Server, CIFS Client, TELNET Server, SNMPv1/v2c/v3, HTTP/HTTPS Server, TFTP Client and Server, ICMPv6, SNTP Client, Web Services (Print/Scan) |
| Wi-Fi Certified | Yes |
| System Requirements | Download System Requirements † |
| Black Copy Speed (max. ppm) | 23 |
|---|---|
| Color Copy Speed (max. ppm) | 23 |
| Copy Resolution | 600 x 600 max. dpi |
| Design Style | Flatbed |
| Duplex Copying | Yes |
| ID Copy | Yes |
| N in 1 Functions | 2in1 / 4in1 |
| Poster Function | Yes |
| Reduction/Enlargement | 25%-400% |
| Sorting Function | Yes |
| Stand-Alone Copying | Yes |
| Carton Dimensions (W" x D" x H") | 20.75" x 23.25" x 22.0" |
|---|---|
| Carton Weight (lbs) | 59.3 |
| Unit Dimensions (W" x D" x H") | 16.1" x 19.0" x 16.1" |
| Unit Weight (lbs) | 51.8 |
| Activity Report/Journal Report | Yes |
|---|---|
| Auto Fax Receive Date/Time Header | Yes |
| Broadcasting (Number of Locations) | 250 |
| Call Waiting/Caller ID/Distinctive Ring Ready‡ | No/No/Yes |
| Document Memory Backup | Yes |
| Duplex Faxing | Yes |
| External TAD Interface | Yes |
| Fax Modem Speed | 33.6K bps |
| Fax Page Memory‡ (max. pages) | 500 |
| Faxing Capability | Black and White |
| Fax/Telephone Switch | Yes |
| Out-of-Paper Reception | Yes |
| PC Fax Capability (Send/Receive)‡ | Yes |
| Quick Scan/Memory Transmission‡ (approx. sec./page) | 2 |
| Total Auto Dial Locations | 200 |
| LCD Display | 3.7" Color Touchscreen |
|---|---|
| Maximum Monthly Duty Cycle‡ | 30,000 pages |
| Optional Memory | No |
| Recommended Monthly Print Volume‡ | 300 to 1,500 pages |
| Standard Memory (MB) | 256 |
| Toner Save Mode | Yes |
| Automatic Document Feeder Capacity (max. pages‡) | 35 |
|---|---|
| Automatic Document Feeder Capacity (max. pages‡) | 35 |
| Duplex Printing Capability | Yes |
| Manual Feed Capacity‡ (sheets) | 1 |
| Maximum Input for ADF (Width/Height) | 8.5"/14" |
| Media Type | Plain, Bond, Recycled Paper, Labels, Envelopes, Glossy Paper ‡ |
| Minimum Input for ADF (Width/Height) | 5.8"/5.8" |
| Output Paper Capacity (sheets) | 100 |
| Paper Handling Size - Manual Feed | Letter, Envelope, Custom Sizes (3.0-8.5" (w), 5.0-14” (l)), Legal, Executive, A4, A5, A6 |
| Paper Handling Size - Paper Tray | Letter, Legal, Executive, A4, A5, B5 |
| Recommended Paper Brands | Xerox 4200DP 20 lb., Hammermill Laser Paper 24 lb., Xerox Recycled Supreme, 3M CG 3300, Avery Laser Label #5160 |
| Sheet Weight - ADF (Min/Max) | 17-24 lbs. |
| Sheet Weight - Manual Feed (Min/Max) | 16-43 lbs. (bond) |
| Sheet Weight - Paper Tray (Min/Max) | 16-28 lbs. (bond) |
| Sorting Function | Yes |
| Standard Paper Input Capacity‡ (sheets) | 250 |
| ENERGY STAR® Certified | Yes |
|---|---|
| EPA ENERGY STAR® TEC Value (kWh/Week) | 2.1 |
| Machine Noise (Ready/Copying) | 30 dB/53 dB |
| Operating Environment: Humidity | 20-80% (w/out condensation) |
| Operating Environment: Temperature | 50-91° F |
| Power Consumption - Power Off/Deep Sleep/Ready/Copying | 1.8W / 70W / 380W / 370W |
| Power Source | 120V AC 60 Hz |
| Black Print Speed ‡ (max. ppm) | 23 |
|---|---|
| Cloud Services‡ (Print) | BOX/BOX for Business, ONENOTE, SharePoint Online, GOOGLE DRIVE™/GOOGLE DRIVE for Business, EVERNOTE®/EVERNOTE Business, ONEDRIVE/ONEDRIVE for Business, DROPBOX/DROPBOX for Business |
| Color Print Speed ‡ (max. ppm) | 23 |
| Consumable Type | Toner Cartridge and Drum |
| Emulation(s) | BR-Script3‡, GDI, PCL6 (PCL XL Class 3.0) |
| First Page Out Time‡ (max. sec.) | 15 (Black) / 16 (Color) |
| Print Technology | Color LED |
| Printer Driver Compatibility‡ | Windows, macOS®, Linux |
| Cloud Services‡ | GOOGLE DRIVE™/GOOGLE DRIVE for Business, ONENOTE, BOX/BOX for Business, EVERNOTE®/EVERNOTE Business, ONEDRIVE/ONEDRIVE for Business, DROPBOX/DROPBOX for Business |
|---|---|
| Duplex Scanning | Yes |
| Included Software | Kofax PaperPort™ SE with OCR for Windows, Presto!® PageManager® with OCR for Mac® |
| Interpolated Scan Resolution‡ (max. dpi) | 19200 x 19200 dpi |
| Mobile Device Scanning‡ | Brother iPrint&Scan |
| Optical Scan Resolution (max. dpi) | 1200 x 2400 dpi (flatbed), 1200 x 600 dpi (ADF) |
| Scan Drivers Included‡ | TWAIN, WIA, ICA, SANE |
| Scan File Formats | JPEG (JPG), PDF Single-page/Multi-page (PDF/A, High Compression PDF, TIFF Single-page/Multi-page (TIF), Windows Bitmap (BMP), MAX |
| "Scan To" Feature‡ | Email, PC (File, Email, Image, OCR), FTP, Network Folder (CIFS - Windows only), E-mail Server (download) |
| Scanning Capability | B/W and Color |
| Security Functions | Setting Lock, Secure Function Lock, Secure Print |
|---|---|
| Wireless Network Security | WEP 64/128 bit, WPA/PSK (TKIP/AES), WPA2-PSK (AES), 802.1x, LEAP(CKIP), EAP-FAST(TKIP/AES), PEAP, EAP-TLS, EAP-TTLS |
| Carton Contents‡ | (1) Starter Toner Cartridges (BK/C/M/Y) (1,000 pgs) (1) DR221CL Drum Unit Set (15,000 pgs) Quick Set Up Guide Software CD-ROM for Windows® Software CD-ROM for Mac® |
|---|---|
| USB Cable | Not Included |
| Warranty | 1 Year Limited |
| Best Transmission Speed (approx. sec./page)‡ | Based on ITU-T Test Chart #1 at standard resolution with JBIG compression. |
| Broadcasting (# of locations) | Black/White only. |
| Call Waiting/ Caller ID/ Distinctive Ring Ready‡ | Check with local phone company for service availability. |
| Cloud Services (Web Connect)‡ | Requires an Internet connection and an account with desired service. All referenced trademarks and registered trademarks are the property of their respective companies. ©2018 Google LLC All rights reserved. Google Drive is a trademark of Google LLC. EVERNOTE is a trademark of Evernote Corporation and used under a license. |
| PC Fax Capability (send/receive)† | Black/White only. |
| Fax Page Memory (max. pages)‡ | Based on ITU-T Test Chart #1 at standard resolution with JBIG compression. |
| Standard Input Paper Capacity (sheets)‡ | Maximum capacity based on using 20 lb paper. |
| USB Direct Interface/PictBridge‡ | Print/Scan: PDF (up to ver. 1.7), JPEG, XPS and Secure PDF files via your USB flash memory drive Scan: PDF/A, Signed PDF, TIFF (mono) USB 2.0 Standard. USB Mass Storage standard from 16MB to 8GB. Support format: FAT12/FAT16/FAT32 |
| Mobile Device Scanning App‡ | Requires connection to a wireless network. |
| Quick Scan/Memory Transmission (approx. sec/page)‡ | Based on ITU-T Test Chart #1 at standard resolution with JBIG compression. |
| Emulation(s) | BR-Script3 is PostScript®3™ compatible |
| Maximum Monthly Duty Cycle‡ | Maximum number of printed pages per month and can be used to compare designed durability between like Brother products. For maximum printer life, it is best to choose a printer with a duty cycle that far exceeds your print requirements. |
| Mobile Device Compatibility‡ | Requires connection to a wireless network. AirPrint is a registered trademark of Apple Inc. Mopria® is a registered trademark or service mark of Mopria Alliance, Inc. in the United States and other countries. Unauthorized use is strictly prohibited. Wi-Fi Direct is a registered trademark of Wi-Fi Alliance®. |
| Recommended Monthly Print Volume‡ | The recommended range of monthly printed pages to achieve the best possible performance and printer life. Printers are intended to handle occasional usage beyond this range with little or no effect. Consistently printing above the recommended print volume, however, may adversely affect the print quality or life of the machine. It is always best to choose a printer with an appropriate recommended print volume to allow for any anticipated increase in printing needs. |
| Max. Automatic Document Feeder Capacity‡ | Maximum capacity based on using 20 lb paper. |
| Standard Interface(s) | USB printer cable not included |
| "In-box" Consumables/Yield‡ | Approximate toner cartridge yield in accordance with ISO/IEC 19798 (letter/A4). Drum yield is approx., and may vary by type of use. |
